Hollyland Pyro 7 Wireless Transceiver Monitor

#4573K7218  PC #HOHLPYRO7
In Stock
Key Features
  • Monitor Wireless Video up to 1300' Away
  • 7" Touchscreen 1920 x 1200 Display
  • Transmitter & Receiver Mode Switching
  • New Capsule Antennas & Record/Playback
  • One Transmitter Can Send to 4 Receivers
  • 1080p SDI Input; Up to UHD 4K30 via HDMI
  • High 1200 cd/m² Brightness
  • Auto Frequency Hopping, 2.4/5 GHz Bands
  • RTMP Streaming, USB/SD Card Import/Save
  • Built-In Dual L-Series Battery Plate
USD 630.00
Color

Specifications

Hollyland PYRO 7 Specs

Information Display Size
7.0" / 17.8 cm
Native Resolution
1920 x 1200
Touchscreen
Yes
HDR Support
No
Media/Memory Card Slot
Single Slot: SD/SDHC/SDXC [Supports Recording]
Wireless
Proprietary Wireless
Video Format
HDMI
UHD 4K: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24
1080i: 60/59.94/50
720p: 60/59.94/50
SDI
1080p: 60/59.94/30/29.97/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
Show Less
Phantom Power
No
Battery
2x L-Series Mount on Included, Interchangeable Plate
Power Consumption
22 W (Maximum)

Inputs/Outputs

Information Antenna I/O
2x RP-SMA Male
Video I/O
1x BNC (3G-SDI) Input
1x BNC (3G-SDI) Output
1x HDMI 1.4b Input
1x HDMI 1.4b Output
Embedded Audio
HDMI/SDI: 8-Channel
Audio I/O
1x 1/8" / 3.5 mm Headphone Output
Built-In Speaker
No
Power I/O
1x Barrel Input
Other I/O
1x USB-C (Firmware) Input
Media/Memory Card Slot
Single Slot: SD/SDHC/SDXC [Supports Recording]
Encryption
No

Display

Information Panel Type
LCD
Display Size
7.0" / 17.8 cm
Native Resolution
1920 x 1200
Aspect Ratio
16:9
Touchscreen
Yes
Maximum Brightness
1200 nits / cd/m2
Contrast Ratio
1000:1
HDR Support
No
LUT Support
Yes
Image Controls
Focus Peaking, Waveform

General

Information Environmental Resistance
No
Operating Conditions
14 to 113°F / -10 to 45°C
Storage Conditions
-40 to 140°F / -40 to 60°C
Material of Construction
Aluminum, Magnesium
Dimensions
7.1 x 5 x 1.3" / 180 x 127 x 31.8 mm (Excluding Antenna)
Weight
1.20 lb / 545.00 g, Excluding Antenna

Power

Information Input Power
10 to 18 VDC at 2.5 A
Battery
2x L-Series Mount on Included, Interchangeable Plate
Power Consumption
22 W (Maximum)

Wireless

Information Wireless
Proprietary Wireless
Wireless Range
1300' / 396.2 m (Line-of-Sight)
650' / 198.1 m
Channel Bandwidth
40 MHz, 20 MHz
Frequency Range
US: 5.1 to 5.8 GHz
US: 2.412 to 2.484 GHz
Latency
60 ms
RF Power
23 dBm
RF Sensitivity
-80 dBm
Wi-Fi
No
Bluetooth
No
Mobile App Compatible
Yes (Required): Android & iOS
App Name: HollyView
Functionality: Adjust Settings, Firmware Update, Remote Control, Setup, View Live Feed

Mounting

Information Tripod/Accessory Mounting
Bottom/Left/Right
1x 1/4"-20 Female

Format Support

Information Video Format
HDMI
UHD 4K: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24
1080i: 60/59.94/50
720p: 60/59.94/50
SDI
1080p: 60/59.94/30/29.97/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
Audio Format
4-Channel
Wireless Video Compression
Compressed
Timecode Support
Yes

Recording

Information Pulldown Conversion
No
Camera Trigger
No
Pre-Roll Record
No
Closed Caption Support
No
Reference Input
No
Phantom Power
No

Packaging Info

Information Package Weight
2.16 lb
Box Dimensions (LxWxH)
8.7 x 6.6 x 3.3"
