BOYA BOYALINK 2-Person All-in-One Wireless Microphone System with Interchangeable Connectors (2.4 GHz)

#566810N57  PC #BOYALINK
In Stock
Key Features
  • For Content Creation, Mobile Journalism
  • 2-Person Shoots with Camera or Phone
  • 2 x Transmitters with Built-In Mic
  • Dual-Channel Receiver
  • 3.5mm TRS, USB-C, Lightning Connectors
  • 328' Transmission Distance
  • USB-C Charging Ports
  • LED Indicators, 6 Levels of Gain Control
  • Built-In Rechargeable Batteries
  • Charging Case
MMK 350,000.00
Color

Specifications

Key Specs

Information Wireless Technology
Analog/Digital Hybrid 2.4 GHz
Included Transmitters
2x Clip-On with Microphone
Diversity
Non-Diversity
Max Operating Range
328.1' / 100 m
Receiver Type
Camera-Mount / Plug-In (Lightning) / Plug-In (USB-C) / Plug-In (1/8" / 3.5 mm TRS)
Microphone Type
Built-In (Transmitter)
Polar Pattern
Omnidirectional

Receiver

Information Receiver Type
Camera-Mount / Plug-In (Lightning) / Plug-In (USB-C) / Plug-In (1/8" / 3.5 mm TRS)
Mounting Options
Plug-In (with Included Hardware)
Antenna
Internal
Number of Audio Channels
2
Audio I/O
1x 1/8" / 3.5 mm TRS Male Unbalanced Output
Frequency Response
20 Hz to 20 kHz
Network I/O
No
USB/Lightning Connectivity
USB-C Male
Lightning Male
USB-C Female (Charging)
USB Class-Compliant
Yes
RF Output Power
10 mW
Power Requirements
Battery
Battery Type
1x Built-In Rechargeable
Internal Battery Capacity
120 mAh
Approx. Battery Life
6 Hours (Lithium Rechargeable)
Display & Indicators
LED
Operating Temperature
32 to 122°F / 0 to 50°C
Storage Temperature
14 to 122°F / -10 to 50°C
Dimensions
2.4 x 0.7 x 0.5" / 61 x 18.2 x 12.8 mm
Weight
0.5 oz / 15 g

System

Information Wireless Technology
Analog/Digital Hybrid 2.4 GHz
Included Transmitters
2x Clip-On with Microphone
Diversity
Non-Diversity
RF Channel Scanning
Auto-Scan
Max Operating Range
328.1' / 100 m
Max Transmitters per Band
2
Built-In Recorder
No
Timecode Support
No
Mobile App Compatible
No
Sample Rate/Resolution
48 kHz / 16-Bit
SNR
>85 dB
THD
<0.01 %

Microphone

Information Microphone Type
Built-In (Transmitter)
Color
Black
Sound Field
Mono
Polar Pattern
Omnidirectional
Frequency Range
20 Hz to 20 kHz
SNR
85 dB
THD
< 0.01%
Sensitivity
-42 dB
Operating Temperature
32 to 122°F / 0 to 50°C
Storage Temperature
14 to 122°F / -10 to 50°C

Charging Case

Information Recharge Time
1.5 Hours
Battery Chemistry
Lithium-Ion
Capacity
1000 mAh
Charging Interface
USB-C
Dimensions
4.4 x 2.9 x 1.3" / 112 x 73 x 33 mm
Weight
3.5 oz / 99 g

Transmitter

Information Transmitter Type
Clip-On with Microphone
RF Output Power
10 mW
Audio I/O
No
Muting
Mute Switch
Auto-Level Control
No
Frequency Response
20 Hz to 20 kHz
Sync Method
2.4 GHz QPSK
Antenna
Internal
Power Requirements
Battery
Battery Type
1x Built-In Rechargeable
Internal Battery Capacity
95 mAh
Approx. Battery Life
10 Hours
USB/Lightning I/O
USB-C (Charging)
Display & Indicators
LED
Operating Temperature
32 to 122°F / 0 to 50°C
Storage Temperature
14 to 122°F / -10 to 50°C
Dimensions
2.3 x 0.6 x 0.5" / 59 x 16.2 x 12.8 mm
Weight
0.4 oz / 12 g

Packaging Info

Information Package Weight
0.56 lb
Box Dimensions (LxWxH)
6.5 x 5 x 2.1"
